Application
All medical instruments and devices are broadly applied in traumatic surgery ,joint surgery ,orthopedic surgery ,neurosurgery operations .K wires or be used in intermediary interlocking nail surgery or arthroscopic surgery. whole unit is autoclavable,imported motor ensure low noise,high speed,high proper alignment ,long service life , the machine is warranty for 12 moths. can adopt various flexible reamer ,chuck easily during the process of surgery .
Spec data
Main data
| Hand piece | working voltage | 14.4 V | ||
| Ooutput power | ≥20 W | |||
| unit rise in temp | ≤25°C | |||
| Charger | Input voltage | AC 220V,50HZ/ 110V,60HZ | ||
| Output power | 14.4v 900ma | |||
| Input power | 30 W | |||
| Battery | voltage | 14.4 V | ||
| charging time | 3 hours | |||
Individual product data
| product | speed | noise | diameter run-out | torque | ||
| Normal bone drill | 0-1300 r/m | ≤65db | ≤0.5mm | ≥1.6NM | ||
| Cannulated bone drill | 0-600 r/m | ≤65db | ≤0.5mm | ≥3.5NM | ||
| Oscillating saw | 0-18000 osc/m | ≤75db | ||||
| AcetabulumSlow drill | 0-300 r/m | ≤65db | ≤0.5mm | ≥6.5NM | ||
| Sternum saw | 0-15000 ocs/m | ≤75db | ||||
| Craniotomy mill | 0-40000 r/m | ≤40db | ||||
Individual product data
| product | speed | noise | torque |
| Grinding drill | 0-40000 r/m | ≤65db | ≥1.25NM |
